Caltech Brings Smartphone 3D Scanners Closer To Reality

In new research that could have wide-ranging effects on how smartphones work, researchers at Caltech have created a chip that can bring 3D printing to handsets.

Nathan Eddy, Freelance Writer

April 6, 2015

4 Min Read
<p align="left">A 3D image produced by the new NCI chip. </p>

IoT Drives The Future Of Connected Cars

IoT Drives The Future Of Connected Cars


IoT Drives The Future Of Connected Cars (Click image for larger view and slideshow.)

Researchers at the California Institute of Technology (Caltech) have developed a new nanophotonic coherent imager (NCI) chip -- a square of silicon less than a millimeter in size. It could shrink 3D imaging technology to a size small enough to fit in a smartphone.

The high-resolution 3D imager could allow users to take a snapshot with smartphone, send it to a 3D printer, and reproduce a replica accurate to within microns of the original object.

Each one of the 16 pixels on the NCI chip uses an instrument called an independent interferometer to make precise measurements based on the interference of light waves.

The technology behind this capability includes LIDAR detection and ranging technology, which uses scanning laser beams to illuminate a target object. LIDAR is the same technology that is employed to help keep driverless cars safely on the road. It was used in a very recent test by engineers at Delphi using an Audio SUV in a coast-to-coast trip.

The work of the Caltech team is described in a paper called, "Nanophotonic coherent imager," and the research first appeared in the February issue of Optics Express. The tests were overseen by Ali Hajimiri, the Thomas G. Myers Professor of Electrical Engineering at the university.

In contrast to a typical smartphone camera, where each pixel represents the intensity of the light received from a specific point in the image, each pixel in an image created by the Caltech team's NCI provides both the distance and intensity information, allowing it to gather information about the object's size and its distance to create an image of its surroundings.

The NCI chip employs an optical concept called coherence, in which light has a consistent frequency and wavelength, to precisely measure the size of the object and the distance of each point on the object from the camera.

The information needed to create a 3D image is then gathered by converting the light into an electronic signal containing the distance and intensity particulars of the object, resulting in a precise measurement of its size and shape.

While the technology so far is limited to a current array of 16 pixels, in the future, the researchers also developed a method for imaging larger objects by first imaging a four-pixel-by-four-pixel section, then moving the object in four-pixel increments to image the next section.

That allowed researches to survey and scan the contours, hills and valleys of the face of a US penny. That scan was precise enough to provide a clear profile of Abraham Lincoln’s likeness and the "2014" date stamped to the right.

[Read more about 3D printing. ]

In addition, the current array of 16 pixels could also be scaled up to hundreds of thousands, which would offer a scanning area vast enough to be useful for driverless cars to monitor minute changes in road traffic, or for health IT applications to more accurately track subtle shifts in a patient’s heartbeat.

"By having an array of tiny LIDARs on our coherent imager, we can simultaneously image different parts of an object or a scene without the need for any mechanical movements within the imager," Ali Hajimiri, a professor of electrical engineering at Caltech, said in an April 3 statement. "The small size and high quality of this new chip-based imager will result in significant cost reductions, which will enable thousands new of uses for such systems by incorporating them into personal devices such as smartphones."

Although 3D imaging capability has been around for decades, more sensitive systems are generally far too big -- not to mention expensive -- to find a home in consumer applications.
